龙迅半导体/Lontium

龙迅半导体/Lontium

龙迅半导体公司专注于高速接口芯片组(HDMI、 DP/eDP/eDPx、USB/Type-C、MIPI/LVDS、高速Repeater/Retimer、光收发模块、车载Serdes)和超高清显示芯片组的研发设计,为高清互通互联,高清多媒体显示及处理提供整体解决方案和技术支持。
公司自成立以来,始终坚持以自主创新驱动企业发展,通过产品的高效迭代、技术能力的持续升级构筑全方位的竞争优势,已掌握了多项国内领先或达到世界先进水平的核心技术,先后推出140余款芯片产品服务全球的客户,广泛应用于安防监控、视频会议、车载显示、显示器及商显、AR/VR、PC及周边、5G及AIoT等多元化的终端场景。公司的技术能力与产品性能近年来正持续受到国内外知名客户的认可,已成功进入鸿海科技、视源股份、亿联网络、脸书、宝利通、思科、佳明等国内外知名企业供应链;高通、英特尔、三星、安霸等世界领先的主芯片厂商已将公司产品纳入其部分主芯片应用的参考设计平台中。同时,公司热衷于与合作伙伴的深入交流,对新应用生态进行提前布局,通过自身的创新设计带给客户产品更好的竞争力,携手客户共同成长。
未来,公司将坚持深耕于高速混合信号芯片领域,以“为数字世界创新数模混合信号技术”为使命,致力于通过技术创新提供高性能的芯片解决方案,力争成为世界领先的高速混合信号芯片方案提供商。

LT9102—MIPI Single-port to MIPI Dual-port

 Single-Port MIPIDSI/CSI Receiver Complian twith D-PHY2.1&DSI1.1&CSI-22.0- 1clock laneand1/2/3/4configurabledata lanes perport- Up to4.5Gbps per data lane Complian twith C-PHY1.2&DSI-21.0&CSI-22.0- 1/2/3configu rable data trios-Up to3.5Gsps per data trio Support BTA(Bus Turnaround) Support up to4K@90Hz RGB 8bpc Suppor tup to8K@60 DSC pass-through  Dual-Port MIPI®DSI/CSI Transmitter Complian twithD-PHY2.1&DSI1.1&DSI-21.0&CSI-22.0- Sup port1/2configu rable ports- 1clocklaneand1/2/3/4configurable...

LT4079:USB2.0/USB3.2Gen1 to SPI/TTL/MIPI/LVDS/eDP

USB2.0/USB3.2Gen1 显卡 USB2.0/USB3.2Gen1 to SPI/TTL/MIPI/LVDS/eDP Converter USB Support 1 USB port Support USB device mode only Support USB2.0 and USB3.2 Gen1 Support USB update FW online Video ProcessSupport 90°/180°/270°rotationSupport CSC, RGB<->YUV444<->YUV422 convertSupport frame rate control function (FRC) Support font-based and bit-map OSD Parameter ComparisonParameterLT3010LT3011LT4911LT4079USB VersionUSB 2.0USB 2.0USB2.0/USB3.2Gen1USB2.0/USB3.2Gen1Bandwidth480Mbps480Mbps5Gbps5GbpsOutputSPI/I2C/UARTTTL/RGBMIPI/LVDSSPI/TTL/MIPI/LVDS/eDPMaximum Resolution480×320720P1080P1080PBuilt-in DRAM×√√√PackageQFN48QFN68QFN48QFN68

LT4911:USB2.0/USB3.2Gen1 to MIPI/LVDS

USB2.0/USB3.2Gen1 显卡 USB2.0/USB3.2Gen1 to MIPI/LVDS Converter ScreenMaximum resolution 1920X1080@60fps USB Support 1 USB port Support USB device mode only Support USB2.0 and USB3.2 Gen1 Support USB update FW online Video ProcessSupport 90°/180°/270°rotationSupport CSC, RGB<->YUV444<->YUV422 convertSupport frame rate control function (FRC) Support font-based and bit-map OSD

USB2.0显卡 LT3010

USB2.0/USB3.2Gen1 to SPI/I2C/UART/TTL/MIPI/LVDS/eDP LT3010 USB2.0 to SPI/I2C/UART Converter < 3.5 InchesSPI ScreenMaximum Resolution 480X320@15Hz or320X240@25Hz USBSupport 1 USB portSupport USB device mode onlySupport USB2.0Support USB update FW online SPI TransmitterSupport RGB565/RGB666Support master modeSupport 8bit SPISPI output format depends on LCD driver
