BC3688-s Bluetooth &Wi-Fi moduleIntroductionBC3688-s is a highly integrated, low-cost and low-powerconsumption module with dual band Wi-Fi6, BT5.4 forwireless application.lts WLAN function supports the USB2.0 /SDl0 3.0 interface, and its BT function supports theUART/PCM interface.The module provides simple legacy and 20MHz/40MHzco-existence mechanism to ensure backward and networkcompatibility. The units, such as...
1. Description The LT84102M is a high performance Analog switch with wide voltage range capability. It supports DisplayPort 1.2/1.4, HDMI 1.4/2.0/2.1, Bi-directional USB3.2 Gen1 switching differential signal, and emerging and proprietary standards.The LT84102M can pass high-speed signals to 1.38V peak to peak differential, with a common-mode voltage from 2V to VCC...
1. General Description The LT8514 is a bridge controller with upstream PCIe Gen3 x1 and downstream four SATA Gen3 ports. It’s a low latency, low cost and low power AHCI controller, which can be used for high speed data transfer between PCIe port and SATA port. The LT8514 is capable of automatic operation...
1. Description LT7912 is a high performance Type-C/DP1.4a or HDMI2.1 to MIPI or LVDS chip for VR/Display application.HDCP RX as the upstream of HDCP repeater, can cooperate with HDCP TX of other chips to realize the repeater function.For Type-C/DP1.4a input, LT7912 can be configured as 1/2/4 lanes. Adaptive equalization makes it...
1. Description LT7911UXD is a high performance DP1.4a to MIPI chip for automotive and video capture application.HDCP RX as the upstream of HDCP repeater, can cooperate with HDCP TX of other chips to realize the repeater function.The Type-C/DP1.4a input support data rate up to 8.1Gbps which provides sufficient bandwidth for 4K@120Hz,...
1. Description LT9611UXD is a high performance Dual-Port MIPI to HDMI2.0 converter. For MIPI input, LT9611UXD features configurable single-port or dual-port with 1 high-speed clock lane, and 1~4 high-speed data lanes operating at maximum 2.5Gbps/lane, Up to 12dB equalization makes it suitable for long distance application.The HDMI interface includes 4 TMDS clock/data...
