Lontium MIPI to HDMI 选型表

MIPI to HDMI：

LT8912BLT9611LT9611EXLT9611UXDLT9711UX
RXPorts12222
MIPID-PHYD-PHYVersionD-PHY 1.11.5Gbps/lane MaxD-PHY 1.22Gbps/lane MaxD-PHY 1.22Gbps/lane MaxD-PHY 1.22.5Gbps/lane MaxD-PHY 2.14.5Gbps/lane Max
Lanes/Port1/2/3/4 configurable1/2/3/4 configurable1/2/3/4 configurable1/2/3/4 configurable1/2/3/4 configurable
MIPI C-PHYC-PHYVersion××××C-PHY1.23.5Gsps/lane Max
Trios/Port××××1/2/3 configurable
AudioI2S/SPDIFI2S/SPDIFI2S/SPDIFI2S/SPDIFI2S/SPDIF
TXVersionHDMI1.4HDMI1.4HDMI1.4HDMI2.0HDMI2.1Combo DP1.4
Max Data Rate1.2Gbps/lane3.4Gbps/lane3.4Gbps/lane6Gbps/lane12Gbps/lane
HDCP×HDCP1.4HDCP1.4HDCP2.3/1.4HDCP2.3/1.4
DSC××××Bypass mode
Integrated MCU××√√√
PackageQFN64-7.5×7.5QFN64-7.5×7.5QFN64-7.5×7.5QFN64-7.5×7.5QFN76-9×9
Note1080P@60Hz Max4K@30Hz Max4K@30Hz MaxPin-to-Pin LT9611UXD4K@60Hz MaxPin-to-Pin LT9611EX8K@30Hz YUV4224K@120Hz Max

Technical Documentation

Product NamePackageDescriptionStatusDownload
LT8912BQFN64-7.5×7.5Single-Channel MIPI DSI Bridge to LVDS/HDMIMP
LT9611QFN64-7.5×7.52-Port MIPI/LVDS ReceiverMP
LT9611EXQFN64-7.5×7.5Dual-Port MIPI to HDMI1.4 ConverterMP
LT9611UXDQFN64-7.5×7.5Dual-Port MIPI to HDMI2.0 ConverterMP
LT9711UXQFN76-9×9Dual-Port MIPI D-PHY/C-PHY to HDMI2.1/DP1.4a ConverterMP
