Lontium MIPI/LVDS/TTL to DP/USB-C 选型表

Lontium MIPI/LVDS/TTL to DP/USB-C 选型表

MIPI/LVDS/TTL to DP/USB-C:

Product Selection

LT8718LT8911EXLT8911EXBLT9711LT9711UX
RXTTL√××××
LVDSLanes/Port×2port with 1.2Gbps/lane Max×2-port with 1.2Gbps/lane Max×
MIPID-PHYD-PHY Version××D-PHY1.22Gbps/lane MaxD-PHY1.2 2Gbps/lane MaxD-PHY2.14.5Gbps/lane Max
Lanes/Port××1-port with1/2/3/4 configurable2-port with1/2/3/4 configurable2-port with1/2/3/4 configurable
MIPIC-PHYC-PHY Version××××C-PHY1.23.5Gsps/trio Max
Trios/Port××××1-portx3-trio/2-portx3trio3-portx2-trio/4-portx1trio
AudioI2S/SPDIF××I2S/SPDIFI2S/SPDIF
TXVersionDP1.2eDP1.4eDP1.4DP1.2DP1.4a/eDP1.5Combo HDMI 2.1
DataRate5.4Gbps/lane Max2.7Gbps/lane Max2.7Gbps/lane Max5.4Gbps/lane Max8.1Gbps/lane Max for DP12Gbps/lane Max for HDMI
Type-Csupport×××√√
DSC×××BypassmodeBypassmode
Integrated microprocessor×××√√
PackageQFN88-10×10QFN64-9×9QFN48-6×6QFN76-9×9QFN76-9×9
Others///AEC-Q100Grade2AEC-Q100Grade2

Technical Documentation

Product NamePackageDescriptionStatusDownload
LT8718QFN88-10×10TTL to DPMP
LT8911EXQFN64-9×9Dual-Port LVDS Bridge to eDPMP
LT8911EXBQFN48-6×6MIPI DSI/CSI Bridge to eDPMP
LT9711QFN76-9×9Dual-Port MIPI/LVDS to DP1.2 with Type-CMP
LT9711UXQFN76-9×9Dual-Port MIPI D-PHY/C-PHY to HDMI2.1/DP1.4a ConverterMP
