Lontium HDMI/DP Switch 选型表

Lontium HDMI/DP Switch 选型表

HDMI/DP Switch：

Product Selection

4-IN 1-OUT Switch3-IN 1-OUT Switch2-IN 1-OUT Switch
LT8641SXELT8641UXLT8641UXELT7641UXLT7641GXLT8631UXLT8631UXELT7621UXLT7621GX
Version4 x HDMI1.44 x HDMI2.04 x HDMI2.04 xHDMI2.0/
DP1.4Combo		4 xHDMI2.1/
DP1.4Combo		3 x HDMI1.43 x HDMI2.02 xHDMI2.0/
DP1.4Combo		2 xHDMI2.1/
DP1.4Combo
Data Rate3.4Gbps/lane6Gbps/lane6Gbps/laneDP: 8.1G x 4lane
HDMI: 6G x 3lane		DP: 8.1G x 4lane
HDMI: 12G x 4lane		3.4Gbps/lane6Gbps/laneDP: 8.1G x 4lane
HDMI: 6G x 3lane		DP: 8.1G x 4lane
HDMI: 12G x 4lane
Max Resolution4K@30Hz4
K@60HzYUV420		4K60Hz4K60Hz4K60Hz8K4K@30Hz
4K@60Hz
YUV420		4K60Hz4K60Hz8K
HDCPHDCP1.4×HDCP2.3/2.2/1.4HDCP2.3/2.2/1.4HDCP2.3/2.2/1.4××HDCP2.3/2.2/1.4HDCP2.3/2.2/1.4
CEC√×√√√××√√
Integrated Microprocessor××√√√××√√
Audio OutputI2S/SPDIF×I2S/SPDIFI2S/SPDIF/TDMI2S/SPDIF/TDM××I2S/SPDIF/TDMI2S/SPDIF/TDM
ARC√×√√√××√√
eARC×××√√××√√
PackageTQFP100-
14×14		QFN128-14×14QFN128-14×14QFN128-12.3×12.3QFN128-12.3×12.3QFN64-9×9QFN64-9×9QFN88-10×10QFN88-10×10
Others/no XTAL/Mixed switchMixed switchPin-to-Pin
LT8631UXE		Pin-to-Pin
T8631UX		Mixed switchMixed switch

Technical Documentation

Product NamePackageDescriptionStatusDownload
LT8641SXETQFP100-14×14HDMI1.4/2.0 4-in 1-out Switch with Digital Audio OutputMP
LT8641UXQFN128-14×14HDMI2.0 4-In 1-Out SwitchMP
LT8641UXEQFN128-14×14HDMI2.0 4-in 1-out switch with Digital Audio OutputMP
LT7641UXQFN128-12.3×12.34x HDMI2.0/DP1.4 with Type-C to HDMI2.0 Mixed SwitchNEW
LT7641GXQFN128-12.3×12.34x HDMI2.1/DP1.4 with Type-C to HDMI2.0 Mixed SwitchNEW
LT8631UXQFN64-9×9HDMI1.4 3-In 1-Out SwitchMP
LT8631UXEQFN64-9×9HDMI2.0 4-In 1-Out SwitchMP
LT7621UXQFN88-10×102x HDMI2.0/DP1.4 with Type-C to HDMI2.0 Mixed SwitchNEW
LT7621GXQFN88-10×102x HDMI2.1/DP1.4 with Type-C to HDMI2.0 Mixed SwitchNEW
