1. General Description The LT8711SXE is a high performance Type-C/DP1.4 to Type-C/DP1.4/HDMI2.0/DP++ converter, with audio output interface. Also, three CC controllers are included for CC communication to implement DP Alt Mode and power delivery function. On-chip USB3.2 Gen1 switch is a high-speed bi-directional switch which provides flexible switching to accommodate connector...
1. General Description The LT8711SX is a high performance Type-C/DP1.4 to Type-C/DP1.4/HDMI2.0/DP++ converter, with audio output interface. Also, two CC controllers are included for CC communication to implement DP Alt Mode and power delivery function. On-chip USB3.2 Gen1 switch is a high-speed bi-directional switch which provides flexible switching to accommodate connector...
1. Description The LT8712SX is a high performance Type-C/DP1.4 to Type-C/DP1.4/HDMI2.0/DP++ converter, with two configurable DP1.4/HDMI2.0 output interfaces and audio output interface. LT8712SX supports both the DisplayPort™ Single Stream Transport (SST) mode and Multi-Stream Transport (MST) mode. When receiving the multiple video/audio streams which are packetized and transmitted over a single...
1. Description The LT947C serializer is a part of Lontium’s long distance video transmission family for Advanced Driver Assistance Systems (ADAS), designed to provide a solution for LVDS, MIPI and TTL video transmission with a maximum 15m coax (POC) or STP cable. The chip delivers an 8.1Gbps/lane forward data channel and...
LT4079--- Product BriefUSB2.0/USB3.2Gen1 to SPI/TTL/MIPI/LVDS/eDP LT4079是一款高性能USB转显示接口转换器，支持USB2.0/3.2 Gen1输入，可输出SPI/TTL/MIPI/LVDS/eDP等多种显示信号。该芯片集成视频发射器、帧率控制DRAM和OSD功能，内置微处理器实现自动控制，支持触摸数据传输和人机交互。提供丰富的接口选项包括I2C/UART/PWM/QSPI，适用于多显示器、智能视觉终端等场景，最高支持1024×600@60fps分辨率，并具备90°/180°/270°屏幕旋转功能。 The LT4079 is a high performance USB2.0/USB3.2Gen1to SPI/TTL/MIPI/LVDS/eDP converter, designed toconnect a USB source to a display panel.The LT4079 integrates an USB2.0/USB3.2Gen1compliant device, and SPI/TTL/MIPI/LVDS/eDP videotransmitter. Also, integrates an embedded DRAM forFrame rate control function and a high-performance OSD.Also supports panel touch data transmission for...
Wi-Fi Version：a/b/g/n/ac Bluetooth Version：BT5.0 Chip Manufacturer：Realtek WIFI&BT Interface 1：PCIE WIFI&BT Interface 2：USB Product Description
